| MODEL | Configuration | Input MBtuH | Output MBtuH | AFUE | CFM | Dimensions HxWxD | Weight Lbs. |
|---|---|---|---|---|---|---|---|
| A80DS2V070A12 | Downflow | 66.0 | 52.0 | 80.0 | 1408 | 14.5x33x28.4 | 130 |
| A80DS2V090B16 | Downflow | 88.0 | 69.0 | 80.0 | 1760 | 17.5x33x28.4 | 153 |
| A80DS2V110C20 | Downflow | 110.0 | 87.0 | 80.0 | 1898 | 21x33x28.4 | 173 |
| A80US2V070A12 | Up / Hor. | 66.0 | 52.0 | 80.0 | 1348 | 14.5x33x28.4 | 128 |
| A80US2V070A12L | Up / Hor. Low Nox | 66.0 | 52.0 | 80.0 | 1348 | 17.5x33x28.4 | 143 |
| A80US2V090B12 | Up / Hor. | 88.0 | 70.0 | 80.0 | 1320 | 17.5x33x28.4 | 143 |
| A80US2V090B16 | Up / Hor. | 88.0 | 70.0 | 80.0 | 1760 | 21x33x28.4 | 154 |
| A80US2V090B16L | Up / Hor. Low Nox | 88.0 | 69.0 | 80.0 | 1760 | 21x33x28.4 | 154 |
| A80US2V090C20 | Up / Hor. | 88.0 | 70.0 | 80.0 | 1931 | 21x33x28.4 | 173 |
| A80US2V110C20 | Up / Hor. | 110.0 | 87.0 | 80.0 | 2024 | 21x33x28.4 | 181 |
| A80US2V110C20L | Up / Hor. Low Nox | 110.0 | 87.0 | 80.0 | 2024 | 21x33x28.4 | 181 |
| A80US2V135D20 | Up / Hor. | 132.0 | 105.0 | 80.0 | 2024 | 24.5x33x28.4 | 199 |
